TEXA AP33 Diagnostic Cable – Benelli / Keeway
TEXA AP33 is a dedicated diagnostic cable designed to connect the TEXA diagnostic tester to the diagnostic socket of Benelli and Keeway motorcycles. It provides stable and secure communication with the ECU, enabling full diagnostics of the vehicle’s electronic systems.
The product is an element of the professional diagnostic system from TEXA and is designed to work in the BIKE environment with IDC6 software.
Intended use
The AP33 cable is used for motorcycle diagnostics:
-
Benelli,
-
Keeway,
equipped with a factory diagnostic connector compatible with the TEXA system.
Connection requirements
NOTE:
The AP33 cable should be used in conjunction with the AP01 main cable.
Alternatively, it is possible to connect directly via the AP54 cable, which acts as a base connection.
The selection of the right configuration is indicated in the TEXA software after selecting a specific motorcycle model.
Diagnostic capabilities
In combination with the TEXA interface, the AP01 (or AP54) cable, and the IDC6 BIKE software, the AP33 cable enables:
-
reading and clearing fault codes,
-
preview of real parameters (Live Data),
-
tests of actuators,
-
reset service inspections,
-
adaptations and basic settings,
-
identification of the ECU and software version.
The range of functions depends on the model and year of the motorcycle.
Compatibility
-
environment: BIKE,
-
motorcycles: Benelli / Keeway,
-
base cable: AP01 (required) or AP54,
-
software: TEXA IDC6 BIKE,
-
TEXA diagnostic interfaces: Navigator TXB 2, TXT, TXT MULTIHUB.
Application
-
professional Benelli and Keeway services,
-
multi-brand workshops,
-
mobile motorcycle services.
